Acoustic insulation is used to reduce noise generated by media flows in industrial pipelines.
This solution consists of a layer of acoustic insulation material encased in a steel sheathing adapted to the pipeline diameter.
Product parameters
Suppression efficiency
Suppression efficiency
Value
Unit
Suppression
5….25
[dB]
Geometric parameters
Geometric parameters
Value
Unit
Pipeline diameter (DN)
DN32…DN1000
Thickness of the sound insulation layer (T)
50…200
[mm]
Shell diameter (D)
140…1416
[mm]
Mass of pipeline acoustic insulation
1…50
[kg/mb]
Usable properties
Usable properties
Parameter
Standard
Combustibility
A1
EN 13162
Operating temperature
-30…+600 C
Corrosion class
C3…C5
EN ISO 12944
